LOCUS builds low-oil, low-temperature vacuum frying machines (LTVFM series) engineered on more than a decade of frying-technology experience. Each unit fries at ~100°C under 720–760 mmHg vacuum, retaining 99.99% of nutrients while cutting oil absorption by up to 50% compared to atmospheric frying — ideal for cashew, banana, jackfruit, mango and vegetable chip lines.
Every machine is fabricated with SS304 food-grade contact parts, PLC control, and an integrated de-oiling (centrifuge) system, and is designed to meet BRCGS, HACCP and Organic Standards. Our in-house engineering and commissioning team ensures your line achieves export-grade output from the first batch.
What is a LOCUS LTVFM vacuum frying machine?
An LTVFM machine is a fully automatic, PLC-controlled batch fryer that cooks under vacuum instead of open atmosphere. Lowering the boiling point of oil to ~100°C preserves colour, flavour and nutrients while a built-in centrifuge de-oils the finished product, giving crisp, low-oil snacks with a longer shelf life than conventional frying.
4 LTVFM Models
15 kg to 75 kg batch capacity, deployed across India & Africa since 2011
Our vacuum frying capabilities
From 15 kg to 75 kg per batch, our LTVFM machines are engineered for high automation, food-grade compliance, and consistent low-oil output.
Low-Temperature Vacuum Frying
Fries at ~100°C under 720–760 mmHg vacuum, retaining 99.99% nutrients and natural colour
Integrated De-Oiling Centrifuge
Built-in centrifugal de-oiling cuts residual oil content by up to 50% versus atmospheric frying
PLC Batch Automation
Programmable frying time, temperature and vacuum cycles for consistent batch-to-batch quality
Multi-Product Flexibility
One line handles cashew, banana, jackfruit, mango and vegetable chips with recipe-level control
LTVFM model range & specifications
Four batch sizes cover trial lines through full production. Every model shares the same SS304 build, PLC control and 720–760 mmHg vacuum frying process — pick the throughput that matches your plant.
LTVFM-15
15 kg raw material/batch · pilot & small-batch lines · SS304 contact parts, 415V 3-phase PLC control.
LTVFM-25
25 kg raw material/batch · mid-scale production · integrated centrifuge de-oiling, 415V 3-phase PLC control.
LTVFM-50 / LTVFM-75
50–75 kg raw material/batch · full production lines · 720–760 mmHg vacuum, ~100°C frying, 99.99% nutrient retention.
| Model | Batch Capacity | Vacuum Level | Frying Temp. | Contact Material | Control |
|---|---|---|---|---|---|
| LTVFM-15 | 15 kg/batch | 720–760 mmHg | ~100°C | SS304 | PLC, 415V 3-phase |
| LTVFM-25 | 25 kg/batch | 720–760 mmHg | ~100°C | SS304 | PLC, 415V 3-phase |
| LTVFM-50 | 50 kg/batch | 720–760 mmHg | ~100°C | SS304 | PLC, 415V 3-phase |
| LTVFM-75 | 75 kg/batch | 720–760 mmHg | ~100°C | SS304 | PLC, 415V 3-phase |
Frequently Asked Questions.
LOCUS offers four vacuum frying models: LTVFM-15 (15 kg/batch), LTVFM-25 (25 kg), LTVFM-50 (50 kg) and LTVFM-75 (75 kg). All operate at 720–760 mmHg vacuum, frying at ~100°C and retaining 99.99% nutrients.
The built-in centrifugal de-oiling system combined with low-temperature vacuum frying cuts residual oil content by up to 50% compared to conventional atmospheric fryers, while keeping colour, flavour and texture closer to the fresh product.
LTVFM machines handle cashew, banana chips, jackfruit, mango, and a wide range of fruit and vegetable snacks. PLC recipe settings let you switch products on the same machine without hardware changes.
Our installations are engineered to comply with BRCGS, HACCP, Organic Standards and ISO food safety requirements. Our team guides plant design to ensure first-audit certification success.
